SD600-A Brushless Electric Screwdriver

Item #: 145915
Certifications:
$5,500.00

This tool typically ships within 3 -4 weeks. For further information, call 408-684-1442.

The SD600-A brushless electric screwdriver delivers precision process control. The electric screwdriver increases produc READ MORE

Calibration Options For This Product:

Add Calibration Service — $60.00

Preset Value is required

Torque Unit is required

Add Calibration Certificate

Time Interval is required

Item(s) successfully added to your cart.

F
T
T

Required Companion Items:

Item #145917
$4150.00
Item(s) successfully added to your cart.

Specs

Model:
SD600-A
Item #:
145915
Drive Size:
1/4" F/Hex
American:
1.3 - 5.2 lbf.in
S.I.:
14.7 - 58.8 cN.m
Metric:
1.5 - 6 kgf.cm
Tool Weight:
12 oz.
Tool Length:
7.33
Minimum Adjustable RPM Range:
190
Maximum Adjustable RPM Range:
71
Grip Dia:
1 1/4"
The SD600-A brushless electric screwdriver delivers precision process control. The electric screwdriver increases productivity as one power tool can be programmed to do the job of multiple conventional assembly tools, saving time, maintenance cost, space and training. The innovative automation torque control system provides the ability to quickly transform the manufacturing area along with the flexibility to make steady product improvements for small or large production batches. The low inertial force provides smooth reaction-less operation with little G force to assembled parts. The failure of a three-cent fastener that isn't properly tightened can lead to catastrophic or latent failures. Fasteners that are insufficiently fastened can vibrate loose and excessive torque can strip threaded fasteners. The power assembly screwdriver provides a consistent repeatable process control and eliminates potential variations.
    • Electric screwdriver is designed for automation applications that provide manufactures with a rapid, reliable and precise method of fastening screws.
    • Reduces the production cycle.
    • Production flexibility and rapid reconfiguration for new production projects.
    • Provides a consistent repeatable process control and eliminates potential variations.
    • Integration control and data exchange.
    • Optimum asset utilization. Tooling expense delivers favorable return of investment.
    • Maintenance and repair are easy and low cost.
    • Requires SDC-24 torque controller.
    • Increase productivity with one power tool instead of 2 - 8 tools. Perfect for cell based manufacturing environments.
    • Electric screwdriver features a high performance brushless motor design that provides durability and reduces the standard maintenance costs associated with brush type electric screwdrivers.
    • Low inertial force provides smooth reaction-less operation with little G force to assembled parts.
    • Lever start tool.
