TSN125 Preset Cam-Over Wrench

Item #: 020252
$937.00
The TSN cam-over torque wrench is a preset torque wrench designed to provide reliable and precise torque control for fas READ MORE
Model:
TSN125
Item #:
020252
Drive Size:
1/2" Sq. Dr.
American:
30 - 90 lbf.ft
S.I.:
40 - 125 N.m
Metric:
4.1 - 12.8 kgf.m
Tool Weight:
3 lbs.
Tool Length:
18.125

Item(s) successfully added to your cart.

Please select your calibration option below before adding to cart

Add Calibration Service — $20.00

Please select an option:
  ADD SERVICE
  NO SERVICE NEEDED

Preset Value is required

Torque Unit is required

Add Calibration Certificate

Please select an option:
  ADD CERTIFICATE
  NO CERTIFICATE NEEDED

Time Interval is required

F
T
T

Product Details

The TSN cam-over torque wrench is a preset torque wrench designed to provide reliable and precise torque control for fastening applications that do not tolerate over-torque conditions. Using a cam-over wrench removes the operator influence out of the torque equation and offers more accurate and repeatable results than a standard click type wrench. As a quality control tool, the torque wrench allows any user to deliver the correct torque with confidence regardless of task and operator skill level.
The preferred and certified ranges of these tools is in accordance with the requirements of ISO 6789 (+/- 4% of indicated setting).

Product Benefits

  • A preset production torque wrench.
  • The wrench slips free when preset torque is reached, thus eliminating overtorquing.
  • Tamper-proof internal adjustment. No external adjustment scale - must be preset using a torque analyzer.
  • Non-length dependent.
  • Fully-supported non-strip ratchet head.
  • Strong corrosion-resistant stainless steel head, protective coated handle and non-slip rubber grip.
  • Features a mechanical torque adjustment locking device (M-TALD). An auto locking single key operation prevents tampering.
  • ESD compliant (TSN25 models only).
