FT-30D Mini Transformer

Item #: 145870
Certifications:
$200.00

This tool typically ships within 3 - 5 weeks. For further information, call 408-684-1442.

The FT-30D is a mini power supply that operates with select Mountz electric screwdrivers. It is a single tool controller READ MORE
Model:
FT-30D
Item #:
145870
Tool Weight:
8.8 oz.
Tool Length:
5.125
Tool Width:
2.75
Tool Height:
1.5
Maximum Output:
1.2A
Output VDC:
30V
Input VAC:
100-230V
The FT-30D is a mini power supply that operates with select Mountz electric screwdrivers. It is a single tool controller that is designed to operate at either 110v and 230v. The unit is can connect with the Scout screw counting system.
    • Operates with Electric Screwdriver Models: LF-Series and BF035 & BF045.
    • Over Heat Protection (OHP) and Over Current Protection (OCP) protect drivers from damage or malfunction.
    • Temperature Detection powers down the unit and resets automatically when the unit restores to acceptable levels.
    • Switching 110V ~ 230V input voltage. The unit will reset itself if the motor/current overload is too high.
    • The unit can be connected to the Scout Screw Counter.
Operates with Electric Screwdriver Models: LF-Series and BF035 & BF045.

The program lock key is required for BF035 & BF045 models. Settings cannot be adjusted without it.
