FT-30D Mini Transformer

Item #: 145870
$190.00

This tool typically ships within 3 - 5 weeks. For further information, call 408-684-1442.

The FT-30D is a mini power supply that operates with select Mountz electric screwdrivers. It is single tool controller t READ MORE
Model:
FT-30D
Item #:
145870
Tool Weight:
8.8 oz.
Tool Length:
5.125
Tool Width:
2.75
Tool Height:
1.5
Maximum Output:
1.2A
Output VDC:
30V
Input VAC:
100-230V

Product Details

The FT-30D is a mini power supply that operates with select Mountz electric screwdrivers. It is single tool controller that is designed to operate at either 110v and 230v. The unit is can connect with the Scout screw counting system.

Product Benefits

    Over Heat Protection (OHP) and Over Current Protection (OCP) protect driver from damage or malfunction.
    Temperature Detection powers down the unit and resets automatically when unit restores to acceptable levels.
    Switching 110V ~ 230V input voltage. Unit will reset itself if motor/current overload is too high.
    Unit can be connected to the Scout Screw Counter.
Operates with Electric Screwdriver Models:  LF-Series and BF035 & BF045.

The program lock key is required for BF035 & BF045 models. Settings cannot be adjusted without it.
