HTC35 Transformer

Item #: 145824
Certifications:
$425.00

This tool typically ships within 3 - 5 weeks. For further information, call 408-684-1442.

The HTC35 is a power supply that operates with HF-Series electric screwdrivers. It is a single tool controller that is d READ MORE
Model:
HTC35
Item #:
145824
Tool Weight:
1.8 lbs.
Tool Length:
7.33
Tool Width:
5.125
Tool Height:
2.5
Maximum Output:
4A
Output VDC:
35V
Input VAC:
110/230V
The HTC35 is a power supply that operates with HF-Series electric screwdrivers. It is a single tool controller that is designed to operate at either 110v and 230v. The unit is can connect with the Scout screw counting system.
    • Operates with the HF-Serieselectric screwdrivers.
    • Over Heat Protection (OHP) and Over Current Protection (OCP) protect drivers from damage or malfunction.
    • Temperature Detection powers down the unit and resets automatically when the unit restores to acceptable levels.
    • Switchable 110V & 230V input voltage. The unit will reset itself if the motor/current overload is too high.
    • Start & Stop Signal Output (for PLC).
    • Screwdriver Lock Signal Input (for PLC).
    • The unit can be connected to the Scout Screw Counter.
Operates with Electric Screwdriver Models: HF-Series
