HF50N-A ESD Brushless Electric Screwdriver

Item #: 145925
Certifications:
$2,165.00
In Stock
The HF-Series brushless electric torque screwdriver provides precision torque control. The electric screwdriver ensures READ MORE
NOTE: Requires Companion Items View

Calibration Options For This Product:

Add Calibration Service — $55.00

Preset Value is required

Torque Unit is required

Add Calibration Certificate

Time Interval is required

Item(s) successfully added to your cart.

F
T
T

Required Companion Items:

Program Lock Key
Item #145774
$45.00
Item(s) successfully added to your cart.
HTC35 Transformer
Item #145824
$505.00
Item(s) successfully added to your cart.
Torque Cover for HF-Series and YF-Series
Item #145903
$105.00
Item(s) successfully added to your cart.

Specs

Model:
HF50N-A ESD
Item #:
145925
Drive Size:
1/4" F/Hex
American:
17.4 - 43.4 lbf.in
S.I.:
196.2 - 490.5 cN.m
Metric:
20 - 50 kgf.cm
Tool Weight:
28.6 oz.
Tool Length:
11.33
Minimum Adjustable RPM Range:
600
Maximum Adjustable RPM Range:
1050
Grip Dia:
1 1/2"
Requires Program Lock Key:
true
The HF-Series brushless electric torque screwdriver provides precision torque control. The electric screwdriver ensures quality and reduces overall assembly failures. These durable power tools feature a Swiss Maxon brushless motor design, which reduces the standard maintenance costs for electric screwdrivers. The brushless screwdriver life cycle is extended and maintains a clean working environment with almost no expendable parts and a simple design. The screwdriver requires less maintenance and part replacement and provides consistently reliable performance. A quality brushless electric screwdriver makes a safer world through accuracy and precision.

Related Products

    • High-performance Swiss Maxon brushless motor design provides durability and reduces the standard maintenance costs for electric screwdrivers. comfort.
    • Designed for high production environments. Minimal heat build-up even when the tool is operated continuously.
    • Adjustable RPM setting on the tool. A selectable Soft Start mode from 0.2-0.6 seconds.
    • Over Heat Protection (OHP) and Over Current Protection (OCP) protect drivers from damage or malfunction. Features a LED display that signals the tool status for the operator to view.
    • External torque adjustment scale.
    • Can be connected with the Scout Screw Counter.
    • Requires an HTC35 transformer (power supply).
    • All models are ESD designed and prevent the occurrence of electro-static discharge, which improves production yields, manufacturing costs, product quality, product reliability, reputation, and profitability.
Requires Program Lock Key (Item # 145774) in order to adjust RPM & Soft Start Settings. Program Lock Key must be plugged into the HTC35 Transformer.
