NFS150-A ESD Brushless Electric Screwdriver

Item #: 145865
$1,445.00
Designed for high production environments, the E-DRIV® NF-Series feature a high performance brushless motor design that READ MORE
Model:
NFS150-A ESD
Item #:
145865
Drive Size:
1/4" F/Hex
American:
2.6 - 13 lbf.in
S.I.:
29.4 - 147 cN.m
Metric:
3 - 15 kgf.cm
Tool Weight:
18.4 oz.
Tool Length:
10.25
Minimum Adjustable RPM Range:
800
Maximum Adjustable RPM Range:
1700
Grip Dia:
1 1/3"
Requires Program Lock Key:
true

Item(s) successfully added to your cart.

Please select your calibration option below before adding to cart

Add Calibration Service — $35.00

Please select an option:
  ADD SERVICE
  NO SERVICE NEEDED

Preset Value is required

Torque Unit is required

Add Calibration Certificate

Please select an option:
  ADD CERTIFICATE
  NO CERTIFICATE NEEDED

Time Interval is required

F
T
T

You will also need

Item #145754
$285.00
Item(s) successfully added to your cart.
Item #145774
$35.00
Item(s) successfully added to your cart.

Product Details

Designed for high production environments, the E-DRIV® NF-Series feature a high performance brushless motor design that provides durability and reduces the standard maintenance costs for electric screwdrivers. The NF tool is ESD safe, ensuring less than 1 Ohm at the bit tip. ESD management in power tools ensures product quality, cost savings and a reduction in overall ESD failures.

Product Benefits

  • Various models that range from 2.6 - 39 lbf.in
  • High performance Swiss Maxon brushless motor design provides durability and reduces the standard maintenance costs for electric screwdrivers.
  • Designed for high production environments. Minimal heat build-up even when tool is operated continuously.
  • Over Heat Protection (OHP) and Over Current Protection (OCP) protect driver from damage or malfunction. Features a LED display that signals the tool status for the operator to view.
  • Can be connected with the Scout Screw Counter.
  • External torque adjustment scale.
  • Requires transformer (power supply).
  • All models are ESD designed and prevent the occurrence of electrostatic discharge, which improves production yields, manufacturing costs, product quality, product reliability, reputation and profitability.
  • Four style of drivers
  • - Standard models: Adjustable RPM setting on the tool. A selectable Soft Start mode from 0.2-0.6 seconds. (Lever Start & Push-to-Start)
  • - Soft Stop models: Precision "Soft-Stop" clutch prevents shock to sensitive assemblies like disk drives, plastics, electronics, etc. (Lever Start)
  • - Angle Control & Auto Reverse models: Set the start, stop and operating direction of the tool. (Lever Start)
  • - Plus models: Features a selectable Double Hit Mode for soft joint applications and a selectable Soft Start mode (from 0.2-0.6 seconds). This option is available for Standard & Soft Stop screwdrivers (Lever Start & Push-to-Start)
Note! - Requires Program Lock Key (Item # 145774) in order to adjust RPM & Soft Start Settings. Program Lock Key must be plugged into the STC40 Transformer (for details).
