TorqueMate® PTT-Series Torque Analyzer
The PTT is a hand-held version of the LTT torque analyzer, making torque testing mobile and easy, from calibration labs to assembly stations. The PTT torque tester offers a quick testing solution to ensure the tools fall within acceptable limits. The torque analyzer is ideal for calibrating and testing hand screwdrivers, wrenches, and power tools.
Highly portable and user-friendly, our battery-powered torque validation system can be carried directly to the assembly line to spot-check tools as part of a QA program or used at assembly stations for quick and easy torque tool validation and calibration, allowing operators and engineers to have maximum confidence in their tooling.
A torque sensor is needed to operate with the PTT unit and is used to calibrate and measure the torque for hand screwdrivers, torque wrenches, and power tools. The PTT torque tester only connects to torque sensors as the instrument does have a built-in internal transducer.
A torque analyzer is a vital instrument for a quality control program. Investing in a torque testing solution eliminates downtime and expenses for shipping tools back and forth to an outside service center. It allows you to calibrate instruments more often and reduce calibration turnaround times and costs.
The PTT is compatible with rotary torque sensors for joint testing and verifying a power tool’s performance. When testing power tools, operators must use a run down adapter to ensure reading accuracy and prevent damage to the torque analyzer.
Easily connect Mountz torque sensors to the Mountz PTT via cable using plug-and-play ARC II technology. Manufacturing teams can connect torque sensors and analyzers with a Mountz multiplexer.and easily switch between up to 4 sensors.
Regularly auditing and validating tooling calibration is essential for reducing errors in your assembly process and preventing product defects for all manufacturers. Companies must control torque to ensure their product’s quality, safety, and reliability aren’t compromised.
Calibrate, Validate, and Maintain Your Tools
- Measure, test & calibrate hand & power tools to ensure proper torque is applied and reduce manufacturing errors on your assembly line.
- Instantly verify that a tool is still in calibration to validate tool performance on the assembly line.
- Improve Traceability: Document and create a historical record of your torque readings.
- Record & store torque measurement data with software included with purchase; no subscription required.
- Use one analyzer with many torque sensors. Plug & Play with Mountz torque sensors. Features ARCII technology, an instant auto-recognition system of the sensor connected to the PTT. See the accessories section to learn how to connect them easily.
- Built-in Li-ion rechargeable battery. High-capacity Li-Ion batteries for long life (30 hrs with standard torque sensors and 16 hrs with brushless rotary sensors).
- ISO 17025 calibration certificate included with analyzer purchase.
CHOOSE THE MODEL BELOW FOR PURCHASING DETAILS
| [object Object] |
|---|
- Measure, test and calibrate hand & power tools to ensure proper torque is applied and reduce manufacturing errors on your assembly line.
- Instantly verify that a tool is still in calibration to validate tool performance on the assembly line.
- Recommended for hand screwdrivers, wrenches or power tools.
- Stores a total of 5,000 data points
- Define testing parameters and acceptance criteria for collecting tool measurements on the device and download them to a PC later.
- Real-time data export via included software. Clock for time stamping of readings. Use a USB connection for data streaming to a PC for live data collection and graphing capabilities.
- EZ-Plug & Play with Mountz torque sensors. Features ARCII technology, an instant auto-recognition system of the sensor connected to the PTT.
- Compatible with all Mountz sensors: reaction and rotary, brushless and non-brushless, as well as those equipped with angle measurement capacities.
- Torque and Angle data is displayed simultaneously when used with Torque and Angle sensors, up to 8000 RPM for angle measurement.
- Easily connect up to 4 torque sensors using the Mountz multiplexer.
- Selection of six operation modes: (Track, Peak, First Peak, Audit, Spindle Audit, and Torque + Angle).
- Seven units of torque measurements: (ozf.in, lbf.in, lbf.ft, cN.m, N.m, kgf.m, kgf.cm). Two units of force measurements: (lbf and kN).
- Easy to use built-in tool tests operation.
- Features Go / No Go visual indicator. LEDs that illuminate when high or low setting is achieved.
- Easy-to-use menu, a six-digit display.
- Five low-pass filter selections (3000, 2000, 1500, 500 and 200 Hz)
- Features a built-in Li-ion rechargeable battery. High capacity Li-Ion batteries for long life (30 hrs with standard torque sensors and 16 hrs with brushless rotary sensors).
- Display accuracy is better than +/- 0.25% of reading
Torque Verification & Calibration:
Data Collection and Analysis:
Connectivity:
User Experience:
Portability:
Mountz Quality Standards:
System Accuracy ± 0.5% of reading from 20% to 100% of full scale
System Accuracy ± 1% of reading from 10% to 20% of full scale
Standard Torque Sensors: Plug and play to expand your torque measurement range.
Rotary Torque Sensors: In-line rotary torque sensors allow you to directly measure the torque and angle a power tool applies to an actual application, giving you the most accurate measurement possible. Rotary torque sensors can also be used to conduct first movement tests, torque studies and audits.
- RTSX torque sensor
- RTSX-A torque & angle sensor
- BLRTSX brushless torque sensor
- BLRTSX-A brushless torque and angle sensor
Cables for connecting Torque Sensors to PTT: Cables must be purchased to connect torque analyzers and sensors.
- Cable to connect BMX to PTT analyzer
- Cable to connect MTX to PTT analyzer
- Cable to connect RTSX to PTT analyzer
- Cable to connect RTSX-A to PTT analyzer
- Cable to connect BLRTSX or BLRTSX-A to PTT analyzer
Improve Your Calibration Process:
Multiplexer: Connect 1-4 torque sensors to the PTT or LTT torque analyzer. Switch between sensors manually or automatically.
Bar Code Reader: It is designed for users who want the ability to scan barcodes on tools and start tool tests automatically with PTT.
Replacement Parts:
Universal Charger (100-240 VAC) and USB Cable: Keep an extra torque analyzer charger on hand to prevent downtime from lost equipment.
Battery Pack: Replacement battery for Mountz PTT torque analyzer.
