LTT250i Torque Analyzer

Item #: 068404
Certifications:
$3,700.00
In Stock

The torque analyzer is designed for calibrating tools, joint testing, auditing, and measuring torque. Torque tools go READ MORE

Calibration Options For This Product:

Add Calibration Certificate — $.00

Time Interval is required

Item(s) successfully added to your cart.

T
F
T

Specs

Model:
LTT250i
Item #:
068404
Drive Size:
1/4" F/Sq
American:
25 - 250 lbf.in
S.I.:
282.5 - 2825 cN.m
Metric:
28.8 - 288 kgf.cm
Tool Weight:
8 lbs.
Tool Length:
11
Tool Width:
9
Tool Height:
2.6
Cal Cert Options Data Set:
Supplied with a Free ISO 17025 Certification of Calibration

The torque analyzer is designed for calibrating tools, joint testing, auditing, and measuring torque. Torque tools go out of calibration with use. To maintain consistent accuracy, torque tools must be checked periodically for wear or defective parts. A power or hand torque tool is a measuring tool that must be properly calibrated and maintained. The LTT-Series is an advanced torque testing and documentation solution. Using a quality torque tester makes a safer world through accuracy and precision. Controlling torque is essential for companies to ensure their product’s quality, safety, and reliability aren’t compromised.

Software Download

Video Guide: How to Install Software. For any technical support needs please contact us.

Accuracy ± 0.5% of reading from 20% to 100%
Accuracy ± 1% of reading from 10% to 20%

Accessories

Standard Torque Sensors: Plug and play to expand your torque measurement range.


Rotary Torque Sensors: In-line rotary torque sensors allow you to directly measure the torque and angle a power tool applies to an actual application, giving you the most accurate measurement possible. Rotary torque sensors can also be used to conduct first movement tests, torque studies and audits.


Cables for connecting Torque Sensors to LTT:
Cables must be purchased to connect torque analyzers and sensors.


Improve Your Calibration Process:
Multiplexer: Connect 1-4 torque sensors to the PTT or LTT torque analyzer. Switch between sensors manually or automatically.

Bar Code Reader: It is designed for users who want the ability to scan barcodes on tools and start tool tests automatically with LTT.

Mounting Brackets: Use a mounting bracket to securely mount your sensor or analyzer to a workstation for improved performance and product protection.

Replacement Parts:

Universal Charger (100-240 VAC) and USB Cable: Keep an extra torque analyzer charger on hand to prevent downtime from lost equipment.

Battery Pack: Replacement battery for Mountz LTT torque analyzer.


Torque Wrench Calibration:

Calibration Hex Step Adapters: When performing torque wrench calibration or testing, adapters are often needed, especially with torque wrenches with open-end heads. Mountz’s calibration hex step adapter features three or four common sizes.


Power Tool Calibration:

Standard Run Down Adapters (RDA’s): These are joint simulators that provide consistent and reliable torque readings for use with power-driven torque control tools. RDAs reduce the impact and irregular peaks that cause poor repeatability. Each RDA has an effective torque range and will supply repeatable torque data within that range if used correctly. The run-down adapter is mounted in line between the tool drive and the transducer.

Analyzer Maintenance and Calibration:

Maintain and calibrate your tools on-site by purchasing calibration equipment to use in-house. The organization that owns the tool must determine a suitable calibration frequency that meets their needs based on the history of equipment performance, application, degree of usage, and management objectives. For most organizations, we recommend 6-month or 12-month calibration intervals.

Calibration Wheels and Calibration Segment Arms: Engineered for calibrating torque analyzers and sensors and ensuring instruments are traceable to National or International Standards, such as N.I.S.T and ISO.

Calibration Hangers and Weights: Calibrated Dead Weight are the official means by which torque analyzers and torque sensors are calibrated and are traced to National or International Standards, such as N.I.S.T, and ISO.

Related Products

    Torque Verification & Calibration:

    • Measure, test and calibrate hand & power tools to ensure proper torque is applied and reduce manufacturing errors on your assembly line.
    • Instantly verify that a tool is still in calibration to validate tool performance on the assembly line.
    • Recommended for hand screwdrivers, wrenches or power tools.


    Data Collection and Analysis:

    • Stores a total of 5,000 data points
    • Define testing parameters and acceptance criteria for collecting tool measurements on the device and download them to a PC later.
    • Real-time data export via included software. Clock for time stamping of readings. Use a USB connection for data streaming to a PC for live data collection and graphing capabilities.


    Connectivity:

    • Features a built-in transducer and can connect to external torque sensors.
    • EZ-Plug & Play with Mountz torque sensors. Features ARCII technology, an instant auto-recognition system of the sensor connected to the LTT.
    • Operates with torque & force sensors. Compatible with all Mountz sensors: reaction and rotary, brushless and non-brushless, as well as those equipped with angle measurement capacities.
    • Torque and Angle data is displayed simultaneously when used with Torque and Angle sensors, up to 8000 RPM for angle measurement.
    • Easily connect up to 4 torque sensors using the Mountz multiplexer.


    User Experience:

    • Selection of six operation modes: (Track, Peak, First Peak, Audit, Spindle Audit, and Torque + Angle).
    • Seven units of torque measurements: (ozf.in, lbf.in, lbf.ft, cN.m, N.m, kgf.m, kgf.cm). Two units of force measurements: (lbf and kN).
    • Easy to use built-in tool tests operation.
    • Features Go / No Go visual indicator. LEDs that illuminate when high or low setting is achieved.
    • Easy-to-use menu, a six-digit display.
    • Five low-pass filter selections (3000, 2000, 1500, 500 and 200 Hz)


    Mountz Quality Standards:

    • Features a built-in Li-ion rechargeable battery. High capacity Li-Ion batteries for long life (30 hrs with standard torque sensors and 16 hrs with brushless rotary sensors).
    • ISO 17025 calibration certificate included with purchase.

Run Down Adapter (RDA-250i) is included with LTT250i. Use the RDA when testing and calibrating the power tool.
