EF180P-A ESD Electric Screwdriver

Item #: 145881
Certifications:
$740.00
In Stock
The EF-Series electric torque screwdriver increases productivity and enhances product quality through precision torque c READ MORE
NOTE: Requires Companion Items View

Calibration Options For This Product:

Add Calibration Service — $50.00

Preset Value is required

Torque Unit is required

Add Calibration Certificate

Time Interval is required

Item(s) successfully added to your cart.

F
T
T

Required Companion Items:

STC30 Plus Transformer
Item #145683
$335.00
Item(s) successfully added to your cart.
Torque Cover for EF080 and EF120 and EF180
Item #145700
$35.00
Item(s) successfully added to your cart.

Specs

Model:
EF180P-A ESD
Item #:
145881
Drive Size:
1/4" F/Hex
American:
1.7 - 15.6 lbf.in
S.I.:
19.6 - 176.6 cN.m
Metric:
2 - 18 kgf.cm
Tool Weight:
11 oz.
Tool Length:
8.5
RPM High:
630
RPM Low:
440
Grip Dia:
1 1/4"
The EF-Series electric torque screwdriver increases productivity and enhances product quality through precision torque control and user comfort. The electric screwdriver automatically shuts off once the preset torque is achieved. The assembly power tools are recommended for tightening small screws, nuts and bolts. The electric screwdrivers is NRTL certified from TUV America, Inc. The certification ensures manufacturing companies that they are purchasing and operating a quality and safe tool for its operators.

Related Products

  • Rugged production tools designed to increase productivity and enhance product quality through precision torque control and user comfort.
  • Ensures accuracy in fastening with precision automatic shut-off clutch once preset torque is achieved.
  • External torque adjustment scale.
  • Can be connected with the Scout Screw Counter.
  • Requires STC 30 Plus Transformer (power supply).
  • All models are ESD designed and prevent the occurrence of electrostatic discharge, which improves production yields, manufacturing costs, product quality, product reliability, reputation and profitability.
Requires STC 30 Plus Transformer (power supply).
